Placa de baza Gigabyte Z790 AORUS MASTER, Socket 1700, DDR5,
3.649,31 lei inclusiv TVA
Stoc epuizat
Placa de baza Gigabyte Z790 AORUS MASTER LGA 1700, Z790, PCIe Gen 5, EATX, 4x DIMM slots, DDR5 7950MHz(OC), 5 x M.2 , 4 x SATA, 10Gb LAN, WIFI 6E, DisplayPort, 11x USB, Type-C
| PCI | 0 |
|---|---|
| Serial-or-Paralel | No/No |
| Video-Connection | DP |
| Wi-FI | Yes |
| Onboard-CPU | No |
| RAID support | Yes |
| Component for | PC |
| USB connector type | USB Type-A, USB Type-C |
| Memory channels | Dual-channel |
| Processor manufacturer | Intel |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Ethernet LAN | Yes |
| USB 3.2 Gen 2x2 Type-C ports quantity | 2 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Audio output channels | 7.1 channels |
| Supported storage drive types | HDD & SSD |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 7 |
| S/PDIF out port | Yes |
| Maximum internal memory | 192 GB |
| HDCP | Yes |
| DisplayPort version | 1.2 |
| DisplayPorts quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| DirectX version | 12.0 |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Parallel processing technology support | Crossfire |
| Model Chipset | Z790 |
| Gaming | Nu |
| Format | E-ATX |
| Soclu Procesor | Socket 1700 |
| Tip Memorie | DDR5 |
| Numar sloturi memorie | 4 |
| Memorie maxima | 192 GB |
| Tip slot interfata grafica | PCIe 5.0 x16 |
| Chipset audio integrat | Realtek |
| Canale audio | 7.1 |
| Wireless | Da |
| USB Type-C | Da |
| HDMI | Nu |
| Thunderbolt | Nu |
| Sloturi M.2 | 5 |
| RJ-45 LAN | 1 |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Unbuffered memory | Yes |
| USB 2.0 connectors | 2 |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| EPS power connector (8-pin) | Yes |
| BIOS type | UEFI AMI |
| BIOS memory size | 256 Mbit |
| Clear CMOS jumper | Yes |
| Supported memory types | DDR5-SDRAM |
| ECC сompatibility | ECC & Non-ECC |
| Number of HDDs supported | 4 |
| RAID levels | 0, 1, 5, 10 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Front panel connector | Yes |
| TPM connector | Yes |
| RGB LED pin header | Yes |
| WiFi-AP antenna jack | 2 |
| Motherboard chipset family | Intel |
| ACPI version | 5.0 |
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Lithium weight per battery | 0.07 g |
| Processor socket | LGA 1700 |
| Supported processor sockets | LGA 1700 |
| Maximum internal memory supported by processor | 192 GB |
| Number of storage drives supported | 9 |
| Maximum resolution | 4096 x 2304 pixels |
| Total number of SATA connectors | 4 |
| Thunderbolt headers | 2 |
| 12V power connector | Yes |
| Number of M.2 (M) slots | 5 |
| Clear CMOS button | Yes |
| Supported memory module capacities | 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Motherboard chipset | Intel Z790 |
| PCI Express x16 slots | 3 |
| Supported storage drive interfaces | M.2, PCI Express 4.0, PCI Express 5.0, SATA III |
| Motherboard form factor | Extended ATX |
| Audio Chip | Realtek ALC1220-VB |
| PC health monitoring | Fan, Noise, Temperature, Voltage, Water cooling |
| Supported memory clock speed (max) | 8000,7950,7900,7800,4000,4800,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600 MHz |
| Ethernet interface type | 10 Gigabit Ethernet |
| LAN controller | Marvell AQtion AQC113C |
| WLAN controller model | Killer Wi-Fi 6E AX1690 |
| Microphone in | Yes |
| Bluetooth | Yes |
| Product colour | Black |
| Batteries included | Yes |
| Bluetooth version | 5.3 |
| Ethernet LAN (RJ-45) ports | 1 |
| Height | 35 mm |
| Cables included | SATA |
| Country of origin | Taiwan |
| Battery weight | 3 g |
| Number of battery cells | 1 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery type | CR2032 |
| Package height | 80 mm |
| Products per shipping (inner) case | 1 pc(s) |
| Headphone outputs | 2 |
| Package depth | 294 mm |
| Package weight | 3.46 kg |
| Depth | 260 mm |
| Width | 30.5 mm |
| Package width | 34.5 mm |
| Producator | GIGABYTE |
| Garantie | 36 |
