Name: Lindy 100m Cat.6 HDMI 4K60 HDBaseT Extender Description
SKU: LY-38340
Price: 4528.85 RON
Availability: OutOfStock

4.528,85 lei inclusiv TVA

Stoc epuizat

SKU: LY-38340 Categorie: Extendere audio-video

Lindy 100m Cat.6 HDMI 4K60 HDBaseT Extender Description Distributes HDMI resolutions up to 100m over Cat.6 network cable via HDBaseT technology Supports HDMI 18G resolutions up to 4K@60Hz 4:4:4, with additional support for HDR ARC Support as well as RS-232, CEC & Ethernet pass-through & bi- directional IR for simple control Supports PoC (Power over cable), requiring a power supply connection from only one side of the installation Technical details Specifications AV Interface: HDMI Interface Standard: HDMI 2.0 Supported Bandwidth: 18 Gbps Maximum Distance: 70m (229.66ft) – 3840×2160@60Hz 4:4:4 8bit 100m (328.08ft) – 1920×1080@60Hz Maximum Resolution: 3840×2160@60Hz 4:4:4 8bit HDCP Support: 2.2 EDID Pass Through: Pass-through Supported Audio: HDMI Audio Pass-through TosLink (Optical) Up to 5.1Ch 3.5mm Up to 2.0Ch Separate Audio Ports: TosLink (Optical), 3.5mm IR Support: 20 – 60KHz CEC Support: Pass-through Serial Interface: RS-232 Transmission Protocol: HDBaseT Transmission Medium: 1 x Cat.6 Laser Class (only for Fibre): – Wavelength (only for Fibre): – Chipset: VS2310TX-A1 Special Features: HDMI Loop Out Port PoC (Power over Cat.6) ARC Support Connectors Transmitter Input: HDMI Type A (Female), 3.5mm IR (Female) Transmitter Output: RJ-45 (Female), TosLink (Optical) (Female), 3.5mm Audio (Female), 3.5mm IR (Female) Receiver Input: RJ-45 (Female), Toslink (Optical) (Female), 3.5mm IR (Female) Receiver Output: HDMI Type A (Female), 3.5mm IR (Female) Bi-directional Ports: RS-232 3-Pin Terminal Block, RJ-45 Ethernet (Female) Power: 5.5/2.1mm Physical Properties Dimensions (approx.) WxDxH: 163x90x16mm (6.42×3.54×0.63in) per unit Housing Material: Metal Net Weight: 0.77kg (1.7lb) Operating Temperature : 0°C – 40°C (32°F – 104°F) Storage Temperature: -20°C – 60°C (-4°F – 140°F) Humidity: 20 – 90% RH (non-condensing) Power Requirements: 24VDC 1A Colour: Black Miscellaneous Packaging Type: Carton Box Packaging Dimensions: 265x70x210mm (10.43×2.76×8.27in) Gross Weight: 1.28kg (2.82lb) Warranty (Years): 2 Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65 Package Contents HDBaseT HDMI Extender, Transmitter HDBaseT HDMI Extender, Receiver IR Emitter Cable, 1.5m IR Receiver Cable, 1.5m 4 x Mounting Ears & 8 x Screws 2 x 3-Pin Terminal Block Multi-country Power Supply (UK, EU, US & AUS) Lindy Manual Purchasing Information No.: 38340 EAN: 4002888383400 https://www.lindy-international.com/100m-Cat-6-HDMI-4K60-Audio-IR-RS- 232-HDBaseT-Extender-.htm?websale8=ld0101.ld021102&pi=38340 &ci=10

Material	Metal
Connectivity technology	Wired
Maximum refresh rate	60 Hz
USB 2.0 ports quantity	2
Maximum digital resolution	3840 x 2160 pixels
USB port type	USB Type-A
Maximum transfer distance	100 m
AC adapter output current	1 A
Cable types supported	Cat6
RJ-45 ports quantity (transmitter)	1
RJ-45 ports quantity (receiver)	1
Transmitter video port type	HDMI
Receiver local video port type	HDMI
Distanta maxima	100 m
Numar porturi RJ-45	2
Interfata HDMI	Da
Numar porturi USB	2
Rezolutie maxima	3840 x 2160 pixeli
Supported bandwidth	18 Gbit/s
AC adapter output voltage	24 V
Transmitter width	16.3 cm
Transmitter depth	9 cm
Transmitter height	1.6 cm
Receiver width	16.3 cm
Receiver depth	9 cm
Receiver height	1.6 cm
Product colour	Black
Operating temperature (T-T)	0 – 40 °C
Harmonized System (HS) code	84733080
Storage temperature (T-T)	-20 – 60 °C
Operating relative humidity (H-H)	20 – 90%
Manual	Yes
Package height	210 mm
Package width	265 mm
Weight	770 g
Package weight	1.28 kg
Package depth	70 mm
Certification	CE, UKCA, FCC, RoHS & REACH
Producator	LINDY
Garantie	24
