Mechanical Hardware PoE LEDs Dimensions 210.4 x 95 x 29
1.255,75 lei inclusiv TVA
Stoc epuizat
Mechanical Hardware PoE LEDs Dimensions 210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14″) Weight 610 g (1.34 lb) Enclosure material Polycarbonate Total non-blocking throughput 9 Gbps Switching capacity 18 Gbps Forwarding rate 13.392 Mpps Networking interface (8) 10/100/1000 MbE RJ45 ports (1) 1G SFP port Managementinterface Ethernetin-band Bluetooth BLE Power method External AC/DC adapter Power supply 27VDC, 4.4A power adapter (included) Supported voltage range 24 – 28VDC Max. power consumption 8W (excludes PoE output) ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV Operating temperature -10 to 50° C (14 to 122° F) Operating humidity 5 to 95% non-condensing Certications CE, FCC, IC PoE interface (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 😎 or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 😎 Max. Passive PoE wattage per port 30W/27VDC Passive PoE voltage range 27VDC System Status RJ45 data ports PoE Speed/link/activity SFP data ports Link/activity
| Additional-Slot | No |
|---|---|
| Wireless-Router | No |
| Rackable | No |
| LAN-Port-Type | Gigabit |
| LAN Ports | 8 |
| Redundant-PSU | No |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Switch type | Managed |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) ports quantity | 8 |
| Switch layer | L2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Fiber uplink ports quantity | 1 |
| Fiber optic connector | SFP |
| DC input voltage | 20 – 28 V |
| Input current | 4.4 A |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Segment | Consumer |
| Viteza transfer | 10/100/1000 Mbps |
| Porturi RJ-45: | Peste 5 |
| Port USB | Nu |
| Montare in rack | Nu |
| PoE | Da |
| SFP module slots quantity | 1 |
| Quick start guide | Yes |
| User guide | Yes |
| Product colour | White |
| Operating temperature (T-T) | -10 – 50 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Depth | 95 mm |
| Manual | Yes |
| Housing material | Polycarbonate (PC) |
| Height | 29 mm |
| Power source | DC |
| Certification | CE, FCC, IC |
| Power consumption (typical) | 8 W |
| Width | 210.4 mm |
| Weight | 610 g |
| LED indicators | LAN, Power, WAN, WLAN |
| Producator | UBIQUITI |
| Garantie | 24 |
